| Material | Hard PVC Film - Matte / Glossy finish | ||
| Glue | Natural rubber glue | ||
| Foil thickness | 130MIC | ||
| Total thickness | 150MIC | ||
| Release film | No | ||
| Release film thickness | / | ||
| PROPERTIES | UNIT | VALUE | TEST METHOD |
| 180°C Peeling strength | N/10mm | 1.8 | EN60454-2,11 |
| Adhesion to backing | N/10mm | 1.5 | EN60454-2,11 |
| Tensile strength | N/10mm | 22 | EN60454-2,8 |
| Elongation | % | 180 | EN60454-8 |
| Electrolytic corrosion | Grade | A/B1.2 | EN60454-2,7.6 |
| Electrical strength-room temp. | KV/mm | 75 | EN60454-2,17 |
| Electrical strength-humid cond. | KV/mm | 70 | EN60454-2,18 |
| Water resistant | / | Yes | PSTC-34 |
| UV Resistant | / | No | |
| Fire resistant | / | No | |
| Moisture resistant | / | Yes | ASTM D1000 |
| Application temperature | °C | 5 ~ +40 | |
| Temperature resistance | °C | -5 ~ +80 | |
| Shelf life | Month | ≥24 | At approx. +20°C and 50% humidity |
